ATX form factor
Intel B860 chipset
8 channel audio Realtek ALC897
geschikt voor core ultra cpu's socket 1851
Geheugen
4 x ddr5 geheugen banken tot 256GB tot 6400Mhz
Onbroad graphics
1 x HDMI - 2.1 maximale resolutie 4K 60Hz
1 x DP - 1.4 maximale resolutie 4K 60Hz
1 x USB-C DP - Thunderbolt ondersteunt DP 2.1 maximale resolutie 4K 60Hz of 8K 60Hz
De maximale te behalen resolutie hangt af van de cpu die u kiest
Uitbreidingssloten
4 x PCIe x16 sloten:
Slot 1 ondersteunt PCIe 5.0 x16
Slot 2 ondersteunt PCIe 4.0 x1
Slot 3 ondersteunt PCIe 4.0 x4
Slot 4 ondersteunt PCIe 4.0 x1
Storage
3 x M.2
M.2 slot 1 ondersteunt PCIe 5.0 x4 2280/2260
M.2 slot 2 ondersteunt PCIe 4.0 x4 2280/2260/2242
M.2 slot 3 ondersteunt PCIe 4.0 x2 2280/2260
4 x SATA 6G
RAID support op sata, RAID 0, 1, 5 en 10
Backpanel
1 x HDMI
1 x DisplayPort
1 x Thunderbolt 4.0 via USB-C 40Gbps
1 x LAN 5GB
2 x USB 3.2 gen1 5Gbps (blauw)
2 x USB 3.2 gen2 10Gbps (rood)
4 x USB 2.0
3 x audio connectors - mini-jack
1 x Clear CMOS button
I/O connectors intern
1x Thunderbolt5 card connector(JTBT5, support RTD3)
1x Power Connector(ATX_PWR)
2x Power Connector(CPU_PWR)
1x Power Connector(PCIE_PWR 8pin)
1x CPU Fan
1x Combo Fan (Pump_Sys Fan)
4x System Fan
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
1x Com Port (JCOM)
1x Tuning Controller connector(JDASH)
2x Addressable V2 RGB LED connector (JARGB_V2)
1x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
4x USB 2.0 ports
4x USB 5Gbps Type A ports
1x USB 10Gbps Type C ports
